Microchip ATTINY24-20PU, 8bit AVR Microcontroller, ATtiny, 20MHz, 2 kB, 128 B Flash, 14-Pin PDIP

Brand

Family Name

ATtiny

Package Type

PDIP

Mounting Type

Through Hole

Pin Count

14

Device Core

AVR

Data Bus Width

8bit

Program Memory Size

2 kB, 128 B

Maximum Frequency

20MHz

RAM Size

128 B

USB Channels

0

Number of PWM Units

2

Number of SPI Channels

1

Number of UART Channels

1

Number of I2C Channels

1

Typical Operating Supply Voltage

2.7 to 5.5 V

Number of CAN Channels

0

Number of USART Channels

0

Dimensions

19.685 x 7.112 x 5.334mm

Program Memory Type

Flash

Number of Ethernet Channels

0

Number of PCI Channels

0

Instruction Set Architecture

RISC

Number of ADC Units

1

Maximum Operating Temperature

+85 °C

Length

19.69mm

ADCs

8 x 10 bit

Minimum Operating Temperature

-40 °C

Height

5.334mm

Number of LIN Channels

0

Width

7.112mm

Pulse Width Modulation

2 x 16 bit, 2 x 8 bit
