Amprobe 37XRA Handheld Digital Multimeter, True RMS, 10A ac Max, 10A dc Max, 750V ac Max

Brand

Multimeter Type

Handheld

Model Number p

37XRA

Display Type

Digital

Functions Measured

AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Decibel, Diode, Duty Cycle, Frequency, Inductance, Logic Test, Resistance

Absolute Maximum AC Current Measurement

10A ac

Absolute Maximum AC Voltage Measurement

750V ac

Absolute Maximum DC Voltage Measurement

1000V dc

Absolute Maximum DC Current Measurement

10A dc

Absolute Maximum Resistance Measurement

40MΩ

Absolute Maximum Capacitance Measurement

400µF

True RMS

Yes

Maximum Frequency

2kHz

AC Current Measurement Resolution

0.01µA ac

DC Current Measurement Resolution

0.01µA dc

AC Voltage Measurement Resolution

100µV ac

DC Voltage Measurement Resolution

100µV dc

Safety Category Level

CAT II, CAT III

Capacitance Measurement Resolution

10pF

Height

60mm

Minimum Operating Temperature

0°C

Best DC Current Accuracy

±1.5% + 10 Digits

Weight

400g

Best Resistance Measurement Accuracy

±2% + 10 Digits

Battery Type

9V

Safety Category Voltage

600 V, 1000V

Width

92mm

Best AC Current Accuracy

±2.5% + 10 Digits

Best AC Voltage Accuracy

±2% + 10 Digits

Best Capacitance Measurement Accuracy

±3% + 5 Digits

Maximum Operating Temperature

+45°C

Length

195mm

Best DC Voltage Accuracy

±0.1% + 5 Digits

Dimensions

195 x 92 x 60mm

Country of Origin

Taiwan, Province Of China
